Pump centrifugalpump vertikal flerstegs Grundfos CRN 64
Pump centrifugalpump vertikal flerstegs Grundfos CRN 64
| Pump centrifugalpump vertikal flerstegs Grundfos CRN 64 | |||||||
| Serie | Fas/ [Hz] | Motoreffekt ( kW**) |
Flöde | Höjd | Anslutning *) | Märkström (A) |
|
| m3/h | m | DN | PN | ||||
| CRN 64-1-1 | 3/50 | 4,00 | 64,3 | 14,34 | 100 | 16 |
7,9 |
| CRN 64-1 | 3/50 | 5,50 | 63,3 | 20,67 | 11 | ||
| CRN 64-2-2 | 3/50 | 7,5 | 63,9 | 29,05 | 14,4-14,0 | ||
| CRN 64-2 | 3/50 | 11,00 | 64 | 44,3 | 20,8-19,8 | ||
| CRN 64-2-1 | 3/50 | 11,00 | 64 | 37,2 | 20,8-19,8 | ||
| CRN 64-3-2 | 3/50 | 15,00 | 64 | 52,8 | 28,0-26,0 | ||
| CRN 64-3-1 | 3/50 | 15,00 | 64 | 59,8 | 28,0-26,0 | ||
| CRN 64-3 | 3/50 | 18,5 | 64 | 68 | 34,5-32,5 | ||
| CRN 64-4-2 | 3/50 | 18,5 | 64 | 74,7 | 34,5-32,5 | ||
| CRN 64-4 | 3/50 | 22,00 | 64 | 91 | 39,5/22,8 | ||
| CRN 64-4-1 | 3/50 | 22,00 | 64 | 83,9 | 39,5/22,8 | ||
| CRN 64-5-2 | 3/50 | 30,00 | 64,3 | 102 | 56,0-51,0 | ||
| CRN 64-5 | 3/50 | 30,00 | 64 | 115,8 | 56,0-51,0 | ||
| CRN 64-6-2 | 3/50 | 30,00 | 64 | 123,9 | 40 | 56,0-51,0 | |
| CRN 64-5-1 | 3/50 | 30,00 | 64 | 108,5 | 16 | 56,0-51,0 | |
| CRN 64-6-1 | 3/50 | 37,00 | 64 | 132,1 | 40 | 68,0-63,0 | |
| CRN 64-7-2 | 3/50 | 37,00 | 64 | 147,5 | 68,0-63,0 | ||
| CRN 64-6 | 3/50 | 37,00 | 64 | 139,4 | 68,0-63,0 | ||
| CRN 64-7-1 | 3/50 | 37,00 | 64 | 154,7 | 68,0-63,0 | ||
| CRN 64-7 | 3/50 | 45,00 | 64 | 165,3 | 81,0-74,0 | ||
| CRN 64-8-2 | 3/50 | 45,00 | 64 | 174 | 81,0-74,0 | ||
| CRN 64-8-1 | 3/50 | 45,00 | 64 | 181,3 | 81,0-74,0 | ||
Notera
*) Motoreffekt 0,37-3,0 kW = 3x220-240 D/380-415 Y
Motoreffekt 4-11 kW = 3x380-415 D
Motoreffekt 15 kW och större = 3x380-415 D/660-690 Y
